TM-48 RAD SERIES

For drilling in the toughest conditions, solid rock, concrete, fractured rock, frozen ground and compacted soils.

Features:
Available in 48″ length for hydraulic drives and 36″ for the TM-48, 8″ to 36″ diameters, carbide bullet style teeth, 3/8″ thick double flighting.

Bullet Tooth Rock Augers 48″ OAL

Heavy duty rock augers for skid steers, backhoe mounted diggers, front-end loader diggers and pendulum posthole diggers with down pressure.

Features include:
3.5” highstrength tube, 3/4″ double flight boring head, double flight, replaceable bullet style carbide teeth and pilot on 1 3/4” square drive and Rockwell 65 hardfacing.

PLEASE SPECIFY BOLT HOLE SIZE WHEN ORDERING

ORDER NUMBER	MODEL	DIAMETER
A08008	RAD 80	8″
A09008	RAD 90	9″
A10008	RAD 100	10″
A12008	RAD 120	12″
A14008	RAD 140	14″
A16008	RAD 160	16″
A18008	RAD 180	18″
A24008	RAD 240	24″
A30008	RAD 300	30″
A36008	RAD 360	36″

Custom augers and drills are available upon request.

TM-48 SRA SERIES

For drilling in the toughest conditions, solid rock, concrete and fractured rock.

Features:
Available in 48″ length for hydraulic drives and 36″ for the TM-48, 4.5″ to 9″ diameters, carbide bullet style teeth. And heavy duty upper flighting.

Features include:
3 1/4″ tube, 3/4″ double flight boring head, heavy duty upper flighting, replaceable bullet style carbide teeth and pilot on 2 3/8″ API Sub and Rockwell 65 hard facing.

PLEASE SPECIFY BOLT HOLE SIZE WHEN ORDERING

ORDER NUMBER	MODEL	DIAMETER
A04518	SRA 450	4.5″
A06018	SRA 60	6″
A07018	SRA 70	7″
A09018	SRA 90	9″

TM-48 SSA SERIES

Heavy duty dirt augers for skid steers, backhoe mounted diggers, front-end loader diggers and pendulum posthole diggers.

Features include:
3 1/4″ tube, 3/8″ double flight cast boring head with replaceable pengo style teeth and fishtail pilot.

PLEASE SPECIFY BOLT HOLE SIZE WHEN ORDERING.

ORDER NUMBER	MODEL	DIAMETER
A04511	SSA 450	4.5″
A06011	SSA 60	6″
A08011	SSA 80	8″
A09011	SSA 90	9″
A10011	SSA 100	10″
A12011	SSA 120	12″
A14011	SSA 140	14″
A16011	SSA 160	16″
A18011	SSA 180	18″
A24011	SSA 240	24″
A30011	SSA 300	30″
A36011	SSA 360	36″

Custom augers and drills are available upon request.

T-Post “PUFF” Augers

The Belltec puff bit is a 2″ rock drill for drilling t-post holes in tough drilling conditions.

Features include:
High strength solid 1 5/8″ center shaft with a CP-16 replaceable carbide pilot. (cutting width of pilot is 2′)

ORDER NUMBER	COUPLER
A02005	Flange
A02005A	2″ Round
A02005B	2 9/16″ Round with 7/8″ hole
A02005C	2″ Hex
A02005D	2 9/16″ Round with 1/2″ hole

2″ Pilot for Puff Drills

ORDER NUMBER	COUPLER
112018	CP-16

Custom augers and drills are available upon request.

Coupler 2 5/8″ Hex

Call for Pricing
